| Model |
Material |
Window Application |
Size |
Height |
Approval Number |
Model AAA
Model AA
Model A (small)
Model B (medium)
Model C (large)
Model D |
Powder Coated Steel |
Double Hung |
9" - 14" W
12" - 21" W
16" - 29" W
22" - 41" W
28" - 53" W
32" - 60" W |
3 Bars minimum up to 10 Bars high |
HDWG 10-86-80 |
| Model CW-1 |
Powder Coated Steel |
Casement |
14" - 28" x 46"
14" - 28" x 42"
14" - 28" x 39"
14" - 28" x 36" |
3 Bars minimum up to 10 Bars high |
HDWG 04-87- 85 |
Model A
Model B
Model C |
Heavy Duty Powder Coated Steel |
HD Double Hung |
l6" - 29" W x 15" H
22" - 41" W x 15" H
28" - 53" W x 15" H |
3 Bars minimum up to 10 Bars high |
HDWG 06-88- 92 |
| Custom Rigid Full Coverage "FG" |
Powder Coated Steel |
All window types Double-Hung, Casement, Hopper, Sliding |
- |
3 Bars minimum up to 10 Bars high (Max height 72") |
HDWG 08-89- 94 |
| Model H |
Powder Coated Steel |
Hopper |
- |
13" H |
HDWG 10-87-89 |
| Window Stops |
Powder Coated Steel or Aluminum |
Sliding |
3/4" x 1 1/2" x 4 1/2" |
- |
HDLD 01-94-04 |
PTD AL Series I
PTD AL Series II
PTD AL Series III
|
Aluminum |
Double Hung |
14.5" - 26.0" x 15"
25.0" - 26.25" x 25.0"
26.5" - 50" x 25.0" |
3 Bars minimum up to 10 Bars high |
HDWG 06-91-07 |
